Zanotti MSB212EB11XX Uniblock SB Packaged Chiller Refrigeration Mono-block +10 to -5DegC 415V~50Hz
These stationary refrigeration systems are designed to provide complete cooling solutions for commercial and industrial applications. With Zanotti's Mini Chiller Units SB, you can rest assured that your products will remain fresh and at the optimal temperature. These units are equipped with advanced technologies that ensure energy efficiency and minimal environmental impact. Plus, they are built to last, so you can count on them to provide reliable performance for years to come. One of the key benefits of the Mini Chiller Units SB is their versatility. They can be used in a wide range of applications, including food processing, beverage storage, and commercial refrigeration. They are also compact and easy to install, making them ideal for businesses of all sizes. At the heart of these units is Zanotti's advanced refrigeration technology. With a powerful quality compressor and a high-efficiency fan and condenser, the uniblock provide exceptional cooling performance while minimizing energy consumption. They are also designed to be easy to maintain, with easy access to all key components for cleaning and servicing.
The Zanotti MSB range of packaged Uni-Mono-bloc units are ready to use and have been specially developed for small cold room applications such as food, public bars and food prep areas but with a multitude of other uses. Thanks to its excellent design, the Zanotti MSB range of Mono-bloc units are quickly installed in comparison to split refrigeration systems and gives the user a good performance and superb product storage conditions in terms of temperature and hygro-metry. This range of MSB model come in chiller format operating from -5DegC to +5DegC with a higher temperature selectable if required on this model. To see what unit is suitable for you see the chart below. This Zanotti MGM Mono-block units are built only from high reliability components that is expected from this Italian manufacturer. The MGM is fitted with a electrical control panel with : On/Off switch with indicator light, microprocessor controlled electronic system-management module with digital display, controlling the refrigeration and defrost functions of the unit and temperature alarm.
Key Product Features:
| Characteristics |
M.U. |
Value |
| Working temperature |
°C |
+10 ÷ -5 |
| Starting mode |
|
Direct |
| Voltage |
Volt-Ph-Hz |
400/3N~/50 |
| Rated input |
kW* |
170 |
| Rated input |
Amp* |
400 |
| Peak current |
Amp |
260 |
| Max current |
Amp |
87 |
| Refrigerant |
|
R134a |
|
GWP |
1430 |
| Defrost |
|
Hot gas |
| Mass |
Kg |
75 |
| Compressor |
|
|
| Type |
|
Hermetic |
| Nominal power |
kW |
17 |
| Condenser |
|
|
| Air flow |
m³/h |
1400 |
| Evaporator |
|
|
| Air flow |
m³/h |
1100 |
| Air throw |
m** |
4 |
| PED Category |
|
0 |
