Toshiba Air Conditioning RAV Ducted Heat Pump Inverter 5Kw to 23Kw Home / Air Conditioning / Toshiba Air Conditioning / Toshiba Air Conditioning RAV Ducted Heat Pump Inverter 5Kw to 23Kw / Toshiba Air Conditioning Chassis MML-AP0124BH1-E 3.5Kw/12000Btu Heat Pump Inverter 240V~50Hz Toshiba Air Conditioning Chassis MML-AP0124BH1-E 3.5Kw/12000Btu Heat Pump Inverter 240V~50Hz Toshiba Air Conditioning Chassis MML-AP0124BH1-E 3.5Kw/12000Btu Heat Pump Inverter 240V~50Hz £1,416.87 £1,180.72 (ex. VAT) Stock Status: In Stock Information Reviews Toshiba air conditioning chassis style heat pumps for commercial and residential applications. Ideal for concealed cooling and heating and multiple area applications or irregular shaped rooms. Toshiba chassis air conditioning units are of robust construction frame, and are fitted with large diameter fans for optimum air volume, whilst maintaining low sound levels. The concealed chassis unit are the perfect solution for perimeter walls and can be hidden behind a decorative panel to blend with any room interior making them the perfect solution for perimeter walls in offices, libraries, hospitals and commercial buildings with large load functions. Extremely compact design, saving valuable space and low operating noise level of 32dB(A). Easy maintenance: removable split front panel and easy access from the right-hand side Product Key Feature's: Model fits in tight voids, compact construction High EER, low annual power consumption Low height single fan outdoor units Cooling operation down to -15°C ambient High CoP, up to record 3.84 Wired remote controller Pipe runs up to 30 meters Low noise 25dBA on low Cold draft prevention on heat pump start up Fault diagnosis Auto re-start after power interruption PRE-CHARGED WITH REFRIGERANT for up to 20 metres pipe length Light weight noise absorbing outdoor unit R22 & R407C replacement technology External static pressure can be raised up to 120Pa Gravity drain Base return air with filter Outdoor Unit SP404ATP-E: Exterior dimensions (mm) 550 x 780 x 290 Net weight kg 40 Power Source Rating MCB A 16A Refrigerant max piping length m 30 Pipe sizes - 1/4" x 1/2" RAV Concealed-Chassis Indoor Unit: Indoor Unit MML- AP0124BH1-E Outdoor Unit RAV- SM404ATP-E Nominal Cooling Capacity kW 3.6 Heating Capacity kW 4.0 EER/COP W/W 2.94/0.05 UK Cooling Total/Sensible kW 3.3/2.1 Heating kW 2.70 Cooling EN14825 Range Min. - Max. kW 0.9 - 4.0 Power Input kW 1.22 Pdesign kW - SEER/Energy Efficiency Class - Seasonal Energy Consumption kWh/a - Heating EN14825 Range Min. - Max. kW 0.8 - 5.0 Power Input kW 0.80 Pdesign kW - SCOP/Energy Efficiency Class - Seasonal Energy Consumption kWh/a - Indoor Data MML- AP0124BH1-E Air Flow High - Medium - Low l/s 133 - 117 - 83 High - Medium - Low m3/h 460 - 400 - 300 Sound Pressure High - Medium - Low dB(A) 36 - 34 - 32 Power High - Medium - Low dB(A) 51 - 49 - 47 Unit Height x Width x Depth mm 600 x 745 x 220 Weight kg 21 Pipe Connection Flare Connections (gas - liquid) inch 3/8 - 1/4 Drain Pipe Connection mm 20 male screw Remote Controller RBC-AMT32E Outdoor Data RAV- SM404ATP-E Operating Range Cooling/Heating °C 46 to -15/24 to -15 Air Flow High m3/h - l/s 2220 - 616 External Static Pressure Pa 5 Sound Pressure High Cooling/Heating dB(A) 49/50 Power High Cooling/Heating dB(A) 64/65 Unit Height x Width x Depth mm 550 x 780 x 290 Weight kg 39 Pipe Connection Flare Connections (gas - liquid) inch 1/2 - 1/4 Min.-Max. Length m 2-20 Maximum Height Difference m ±10 Drain Port Connection mm 16 Refrigerant R410A Base Charge/Chargeless Length kg/m 1.4/15 Additional Charge Liquid Side g/m 20 Run Current Maximum A 5.69 Power Cable Outdoor to Indoor 3 core + earth Power Supply Suggested Fuse Size V/ph/Hz-A 220-240/1/50-10 PDF Data: These air conditioning units must be installed by an F-Gas qualified engineer. We can install the unit for you using our F-Gas Certified Engineers. Please note if you do not select our installation service we will not ship the unit until we have obtained evidence from you that you will have the unit installed by an F-Gas qualified engineer. This is a requirement of the Article 11 (5) EC/517/2014 on fluorinated greenhouse gases and The Fluorinated Greenhouse Gases Regulations 2015. Not yet reviewed Write an online review and share your thoughts with other shoppers! Be the first to review this product Related Products Air Conditioning Pipe Kit 1/4" + 1/2" £80.03 £66.69 (ex. VAT) Mitsubishi Electric Air Conditioning PEAD-RP50JAQ Ducted Concealed Inverter Heat Pump 5Kw/18000Btu A+ 240V~50Hz £2,791.98 £2,326.65 (ex. VAT) Toshiba Air Conditioning Ducted RAV-SM806BTP-E 7Kw/24000Btu Heat Pump Inverter A 240V~50Hz £2,424.79 £2,020.66 (ex. VAT) 15 meter Installation Pipe Kit 1/4" And 1/2" For Air Conditioning And Refrigeration £183.92 £153.27 (ex. VAT) LG Air Conditioning CM18N14 Concealed Ducted Heat Pump 5Kw/17000 Btu Standard Inverter A++ 240V~50Hz £1,798.95 £1,499.13 (ex. VAT)
