Sunware Marine Modules

Sunware Solar Panel SW3063 12V 24 watt Marine Module

Sunware Solar Panel SW3063 12V 24 watt Marine Module

£347.70 £289.75 (ex. VAT)
Stock Status: Sold Out
Sorry, this item is out of stock

Sunware Solar Panel SW3063 12V 24 watt  Marine Module
SunWare solar modules are designed and tested specifically for use in marine and salt water.The modules are completely maintenance free, durable, and weatherproof. Even under extreme exposure to UV rays whether in the Caribbean, the Mediterranean,or the North Sea SunWare solar modules are always a reliable partner. Their distinctive feature: all 12V standard solar modules are designed with 40 cells. Consequently, SunWare solar modules can be fitted without rear ventilation.Thus, any voltage drop due to high outside temperatures is compensated by the 4 additionally integrated cells to enable a full recharge of the battery.

The back of the module is completely flat so that it can be screwed or glued flush to the deck. SunWare standard solar modules should always be fitted to a firm, inflexible surface. The modules can be fitted flat to deck surfaces with a curving of up to 3%. Due to the extremely flat module structure, the module only adds 3mm, and 15mm at the cable outlet. The 3m PU sheathed cable is robust, UV resistant and weatherproof. To reduce the risk of slipping in wet conditions, the module surface is slightly structured. Within the scope of constant quality control, each individual module is tested and calibrated prior to delivery.

Model SW-3063
Voltage at Pmax [v] 24
Current at Pmax [A] 1.65
Open Circuit Voltage [V] 24.6
Short Circuit Current [A] 1.2
Length [mm] 467
Width [mm] 459
Depth of Jnct Box [mm] 30
Weight [Kg] 4.5
Cell Size [mm] 35 x 105
Max. system voltage 12
Operating Temp -40… +90 °C
Cabel [qmm] 2 x 1,5
Drill hole [mm] 4 pieces, D=5,5
