Introduction:

The PSP 48FB60/3V-2 is a powerful 3-phase external rotor axial fan with a 600mm blade diameter, engineered for high-volume airflow in commercial and industrial HVAC systems. Operating at 400V~50Hz/60Hz, this 2-pole fan is ideal for condenser units, heat exchangers, and ventilation systems requiring robust performance, compact design, and dependable operation.

Key Product Features:

• 400V~50Hz/60Hz three-phase power supply

• External rotor motor for space-saving installation

• 2-pole high-speed design for efficient air delivery

• 600mm dynamically balanced fan blades

• Can be mounted for suction or blowing applications

• Galvanised steel housing with corrosion-resistant coating

• IP44 motor protection class for industrial reliability

• Compact design ideal for retrofitting or confined spaces

• Terminal box included for quick and secure connection

• Trusted PSP build quality for heavy-duty applications

Technical Specifications:

• Model: 48FB60/3V-2

• Voltage: 400V~50Hz/60Hz

• Phase: Three-phase

• Motor Type: External Rotor

• Motor Poles: 2-pole

• Diameter: 600mm

• Speed: ~1300 RPM

• Direction: Suitable for blowing or suction

• Protection Rating: IP44

• Mounting Style: Panel or bracket

• Frame Construction: Galvanised steel

Disclaimer:
Ensure compatibility with system voltage and application. Installation should be performed by a qualified technician in compliance with local regulations.
