Introduction:

The PSP 48FB50L-2 is a long nose external rotor axial fan engineered for optimal performance in condenser units, heat exchangers, and general ventilation systems. With a robust 500mm diameter blade, this 2-pole axial fan operates at 230V~50Hz/60Hz and is designed for installations that demand extended airflow reach or where deeper mounting profiles are required. Its reliable operation and durable construction make it ideal for commercial and industrial HVAC applications.

Key Product Features:

• 230V~50Hz/60Hz single-phase operation

• Extended "long nose" construction for deeper assemblies or extended airflow paths

• 2-pole external rotor motor for compact, high-speed performance

• Galvanised steel frame with protective coating

• Suitable for suction or blowing applications

• Quiet, dynamically balanced fan blades

• IP44 motor protection for dust and moisture resistance

• Pre-installed terminal box for simple wiring

• Trusted PSP quality for industrial and refrigeration systems

Technical Specifications:

• Model: 48FB50L-2

• Voltage: 230V~50Hz/60Hz

• Motor Type: External Rotor

• Motor Poles: 2-pole

• Diameter: 500mm

• Design: Long Nose

• Speed: ~1300 RPM

• Application Direction: Can blow or suck

• Protection Rating: IP44

• Mounting: Panel or bracket mount

• Frame Material: Galvanised steel

Disclaimer:

Ensure suitability for your application before installation. All electrical connections must be carried out by a qualified technician and conform to local regulations.
