Introduction:

The PSP 120FB75/7VT is a high-performance three-phase axial fan featuring a 750mm diameter blade and external rotor motor construction. Engineered for industrial-grade airflow, this 6-pole fan operates at a lower speed for reduced noise, making it ideal for HVAC systems, condenser units, and ventilation projects requiring continuous, reliable air movement with reduced acoustic output.

Key Product Features:

• 400V~50Hz/60Hz three-phase operation

• 750mm fan blade diameter

• 6-pole motor for quieter, smoother airflow

• External rotor design for efficiency and compact form

• IP54-rated housing for dust and water protection

• High durability galvanised frame and corrosion-resistant finish

• Versatile mounting for blowing or suction applications

• Robust for continuous operation in commercial/industrial settings

• Reliable terminal box for electrical access

• Suitable for refrigeration, extraction and ventilation systems

Technical Specifications:

• Model: 120FB75/7VT

• Voltage: 400V~50Hz/60Hz

• Phase: Three-phase

• Motor Type: External Rotor

• Motor Poles: 6-pole

• Diameter: 750mm

• Speed: ~700 RPM (nominal)

• Direction: Blowing or suction

• Protection Rating: IP54

• Construction: Galvanised steel frame

• Application: Ventilation, HVAC, refrigeration systems

Disclaimer:

All electrical and mechanical installations must be carried out by qualified professionals in compliance with local regulations and the product’s specifications.
