This Kit Includes:

1 × Powrmatic SQ60V3 Electric Quartz Vertical Industrial Infrared Heater
1 × Quartz infrared heating lamp assembly (3 × 2kW)
1 × Adjustable wall or suspension mounting bracket
1 × Protective heater guard and aluminium reflector housing
1 × Factory pre-wired electrical connection terminal

1 × SQ60RVC 6kW Remote Variable Heater Controller

High Capacity Vertical Quartz Infrared Heater for Industrial Zones

The Powrmatic SQ60V3 Electric Quartz Infrared Heater is a powerful radiant heating solution designed to provide rapid, efficient warmth in industrial and commercial environments. Using shortwave quartz infrared technology, the heater delivers instant radiant heat that warms people, machinery and working surfaces directly rather than heating the surrounding air.

Infrared heating is particularly effective in warehouses, workshops and large industrial buildings where traditional warm-air heating systems often lose efficiency due to high ceilings, open doors or large air volumes. By directing heat precisely into the occupied working zone, infrared heaters provide immediate comfort while minimising wasted energy.

The SQ heater range has been engineered specifically for zonal heating applications. Instead of heating the entire building space, these heaters focus warmth where workers are located, improving comfort and reducing operating costs in large industrial environments. This targeted heating approach can significantly improve energy efficiency and reduce overall heating demand.

The SQ60V3 model delivers 6kW of radiant heating output using three high-intensity quartz lamps. Its vertical heater configuration produces a wider heat spread compared with horizontal models, making it ideal for entrances, standing work zones and industrial areas where broader heating coverage is required.

Key Product Features:

• Electric quartz shortwave infrared radiant heating technology
• Heat output: 6kW / 21,000Btu
• Instant heat output with no warm-up delay
• Vertical heater configuration for wider heating coverage
• Direct radiant heat to people and working surfaces
• Industrial aluminium reflector housing with protective guard
• Wall mounted or suspended installation options
• Ideal for warehouses, workshops and production areas
• Compatible with SQ60RVC remote heater controller
• Energy-efficient zonal heating solution for large buildings

Technical Specifications:

Model: SQ60V3

Product Type: Electric Quartz Infrared Heater

Heat Output:
6kW / 21,000Btu

Heating Technology:
Quartz shortwave infrared radiant heating

Electrical Supply:
220-240V~50Hz 1Ph

Heating Elements:
3 × 2kW quartz infrared lamps

Mounting Type:
Vertical wall mounted or suspended installation

Applications:

• Warehouses and distribution centres
• Industrial workshops
• Production line workstations
• Loading bays and dispatch areas
• Agricultural buildings
• Retail warehouses

Accessories:

Specifications may be subject to change based on manufacturer updates. Images are for illustrative purposes only.
