This Kit Includes:

1 × Powrmatic SQ45H3 Electric Quartz Vertical Industrial Infrared Heater

1 × Quartz infrared heating lamp assembly (3 × 1.5kW)

1 × Adjustable wall or suspension mounting bracket

1 × Protective heater guard and aluminium reflector housing

1 × Factory pre-wired electrical connection terminal

1 × SQ60RVC 6kW Remote Variable Heater Controller

High Output Vertical Quartz Infrared Heater for Industrial Work Zones

The Powrmatic SQ45H3 Electric Quartz Infrared Heater is a powerful industrial heating solution designed to deliver fast and efficient radiant warmth to commercial and industrial environments. Using high-intensity shortwave quartz infrared technology, the heater produces instant radiant heat that warms people, machinery and surfaces directly rather than heating the surrounding air volume.

Infrared heating is particularly effective in large buildings such as warehouses, workshops and manufacturing facilities where heat loss can occur due to high ceilings, open doors or large air volumes. By delivering targeted warmth directly into occupied zones, the SQ heater range provides rapid comfort while significantly improving heating efficiency.

The SQ range has been developed as a zonal heating system, meaning heat is applied precisely where workers are located rather than attempting to heat the entire building space. This approach reduces wasted energy and can lower operating costs while improving comfort levels in industrial environments.

The SQ45H3 model provides 4.5kW of radiant heating output using three high-intensity quartz lamps and features a vertical heater configuration. This design produces a wider heating spread compared with horizontal units, making it well suited to entrances, workstation areas and industrial zones where broader coverage is required.

Key Product Features:

• Electric quartz shortwave infrared radiant heating technology
• Heat output: 4.5kW / 15,000Btu
• Instant heat output with no warm-up delay
• Vertical heater configuration for wide area heating coverage
• Direct radiant heat to people and working surfaces
• Industrial aluminium reflector housing with protective guard
• IP65 rated construction for demanding industrial environments
• Wall mounted or suspended installation options
• Suitable for warehouses, workshops and production lines
• Compatible with SQ60RVC remote heater controller

Technical Specifications:

Model: SQ45H3

Product Type: Electric Quartz Infrared Heater

Heat Output:
4.5kW / 15,000Btu

Heating Technology:
Quartz shortwave infrared radiant heating

Electrical Supply:
220-240V~50Hz 1Ph

Heating Elements:
3 × 1.5kW quartz infrared lamps

Mounting Type:
Vertical wall mounted or suspended installation

Ingress Protection:
IP65

Applications:

• Warehouses and distribution centres
• Industrial workshops
• Production line workstations
• Loading bays and dispatch areas
• Agricultural buildings
• Retail warehouses

Accessories:

Specifications may be subject to change based on manufacturer updates. Images are for illustrative purposes only.
