REF. NO.

DESCRIPTION & NAME

QTY.

WH-MDC09C3E5 / WH-MDC12C6E5, WH-MDC14C6E5, WH-MDC16C6E5

1

BASE PAN ASS’Y

1

CWD52K1251

2

COMPRESSOR

1

5JD420XAA22

3

ANTI-VIBRATION BUSHING

3

CWH50055

4

NUT FOR COMP. MOUNT.

3

CWH561049

4a

PACKING

3

CWB811017

5

CRANKCASE HEATER

1

CWA341053

6

CONDENSER COMPLETE

1

CWB32C3035

7

HIGH PRESSURE SENSOR

1

CWA50C2570

8

DISCHARGE MUFFLER

1

CWB121014

9

PRESSURE SWITCH

1

CWA101013

10

3-WAYS VALVE (GAS)

1

CWB011251

11

4-WAYS VALVE

1

CWB001046

12

3-WAYS VALVE (LIQUID)

1

CWB011292

13

STRAINER

2

CWB111032

20

SOUND PROOF MATERIAL

- COMP

1

CWG302265

21

SOUND PROOF MATERIAL

1

CWG302266

22

SOUND-PROOF BOARD ASS’Y

1

CWH15K1019

23

V-COIL COMPLETE

- 4-WAYS VALVE

1

CWA43C2169J

24

V-COIL COMPLETE - EXP. VALVE

1

CWA43C2385

25

SENSOR-OD TEMP./COIL

1

CWA50C2730

26

SENSOR-COMP.DISCHARGE

1

CWA50C2576

27

SENSOR-COMP. TOP

1

CWA50C2629

27a

SENSOR-COMP. DEF.

1

CWA50C2577

28

CABINET REAR PLATE

1

CWE02K1019A

29

CONTROL BOARD CASING

1

CWH10K1049

31

TERMINAL BOARD ASS’Y

1

CWA28K1213

36

ELECTRONIC CONTROLLER (CAPACITOR)

1

CWA746169

38

ELECTRONIC CONTROLLER (NOISE FILTER)

1

CWA745446

44

ELECTRONIC CONTROLLER (MAIN)

1

CWA73C4888R

46

REACTOR

2

G0C592J00004

48

TERMINAL COVER

1

CWH171039A

49

NUT FOR TERMINAL COVER

1

CWH7080300J

50

BRACKET FAN MOTOR

1

CWD54K1024

50a

SCREW-BRACKET FAN MOTOR

2

CWH551040J

53

FAN MOTOR (UPPER)

1

EHDS80AAC

54

FAN MOTOR (LOWER)

1

EHDS80BAC

54a

SCREW-FAN MOTOR

8

CWH551016J

55

PROPELLER FAN

2

CWH00K1006

56

NUT for PROPELLER FAN

2

CWH561051

57

CABINET FRONT PLATE

1

CWE061098A

58

DISCHARGE GRILLE

2

CWE201073

59

CABINET SIDE PLATE

1

CWE04K1023A

60

WIRE NET

1

CWD041103A

61

CABINET TOP PLATE COMPLETE

1

CWE031140A

62

ACCESSORY COMPLETE

1

CWH82C1535

66

CABINET FRONT PLATE

1

CWE061274A

67

HANDLE

2

CWE161014

68

TUBE ASS’Y (CAPILLARY TUBE)

1

CWT07K1541

70

EXPANSION VALVE

1

CWB051028
