Key No.

Part No.

Description

Q'ty

Q'ty

Reference No.

1

CV7010000046

CHASSIS ASSY.

1

1

ACXD50K00090

2

CWH50154

ANTI-VIBRATION BUSHING

3

3

H50154

*

3

CV7010000243

COMPRESSOR

1

1

ACXB09-00880

*

4

ACRA50C3321

THERMISTOR (TD)

1

1

A50C3321

5

CWH171058

TERMINAL COVER

1

1

H171058

6

CV7080300J

NUT

1

1

7080300J

7

CWG302839

SOUND PROOF MATERIAL

1

1

G302839

8

CVH56000J

NUT

3

3

CWH56000J

9

CWD541230

FAN MOTOR BRACKET

1

1

D541230

10

CV7010000047

DC MOTORS (BRUSHLESS GENERAL USE)

1

1

L6CBYYYL0178

11

CV7010000244

SCREW

4

4

ACXH55-00270

12

CWH03K1060

FAN ASSY

1

1

H03K1060

13

CWH56053J

NUT

1

1

H56053J

14

CV7010000049

FIN & TUBE CONDENSER COMPLETE

1

1

ACXB32C00640BS

15

CWD912491

PARTICULAR PLATE

1

1

D912491

16

CWG123009

ADH. POLY-E. FOAM

1

1

G123009

17

CVB001116

4-WAYS VALVE

1

1

B001116

18

CV7010000245

TUBE ASSY

1

1

ACXT00-08370

19

CV7010000246

DISCHARGE MUFFLER

1

1

ACXB12-00210

*

20

CWA101007

PRESSURE SWITCH

1

1

A101007

21

CV7010000247

TUBE ASSY

1

1

ACXT00-08380

22

CV7010000248

3-WAYS VALVE

1

1

ACXB01-00550

23

CV7010000249

DISCHARGE MUFFLER

1

1

ACXB12-00220

24

CV7010000250

MULTIBENT TUBE

1

1

ACXT30-10130

25

CV7010000251

TUBE ASSY

1

1

ACXT00-08330

26

CV7010000252

TUBE ASSY

1

1

ACXT00-08360

27

CV7010000059

ACCUMLATOR

1

1

ACXB13-00020

28

CV7010000060

TUBE ASSY

1

1

ACXT00-01890

*

29

CVB051079

EXPANTION VALVE

1

1

B051079

30

CWB11094

STRAINER

1

1

B11094

31

CWH351302

HOLDER-COUPLING

1

1

H351302

32

CWB021657

2-WAYS VALVE

1

1

B021657

33

CV7010000061

RUBBER

1

1

ACXG25-00050

34

CWH4090023

HOSE BAND

3

3

4090023

35

CV7010000253

BUSHING

1

1

ACXH51-00080

36

CV7010000062

BUSHING

1

1

ACXH51-00100

37

KG5AF80-100

BUTYL TAPE

1

1

KG5AF80-100

38

KG2AF75-75

BUTYL TAPE

1

1

KG2AF75-75

39

CV7010000229

BUTYL TAPE

1

1

KG2AF75-100

40

CWH511125

BUSHING

1

1

H511125

*

41

CWD912492

PARTICULAR PLATE

1

1

D912492

42

CVE5A20-60

POLY-E.FOAM

1

1

E5A20-60

43

CVE3A40-40

POLY-E.FOAM

1

1

E3A40-40

44

CV7010000063

BUSHING

1

1

ACXH51-00090

45

CV7010000254

PARTICULAR PIECE

1

1

ACXD93-02510

46

E12A10-450

POLY-E.FOAM

1

1

E12A10-450

47

CWH15C1090

SOUND-PROOF BOARD-COMPLETE

1

1

CWH15C1090

48

CV7010000255

FIXED INDUCTORS

1

1

G0C123J00031

49

EN15A20-20

POLY-E.FOAM (FLAME PROOF)

1

1

EN15A20-20

50

D3A10-230

EPT SEAL

1

1

D3A10-230
