Hyundai HYMD500B 500Kg Battery Powered Mini Dumper Brushless Motor, Hydraulic Tilt 48V, 32Ah
In The Box:
Hyundai HYMD500B Mini Dumper,
Assembly Tools & User Manual.
Introducing the HYMD500B, a high-capacity battery-powered mini dumper by Hyundai, designed with construction sites, farms, and large gardens in mind. It is your go-to solution for transporting materials such as gravel, sand, and aggregates with ease.
Featuring a robust hydraulic tilt bucket, the HYMD500B makes unloading a breeze and can efficiently handle substantial payloads up to 500kg. With its 48V, 32Ah battery powering a brushless motor, and large pneumatic tyres, this mini dumper ensures reliable traction across challenging terrains.
Powerful 48V, 32Ah Battery:
This transport powerhouse comes equipped with a 48V, 32Ah battery, which drives a 1000W Brushless DC motor. It's designed to transport even the bulkiest and most cumbersome materials for up to 10 hours*, navigating inclines of up to 15 degrees with ease. The brushless motor technology amplifies efficiency and power, guaranteeing a prolonged battery lifespan to complete your tasks.
Sturdy Design & Construction:
The HYMD500B boasts a robust design featuring solid-steel construction, a brushless motor, and large tyres, simplifying the transport of hefty materials. Its versatile 4-speed gearbox (three forward and one reverse) allows for speed adjustments to match your workload and pace.
Navigating tight spaces? The 360° rotating rear wheels of the HYMD500B facilitate easy turns and maneuvers, proving invaluable in back gardens or narrow passages.
Hydraulic Powered Bucket Tilt:
The built-in Hydraulic Power Unit of the HYMD500B ensures that unloading hefty contents is no longer a strenuous task. Position the mini dumper, engage the handbrake, load up, transport, and then effortlessly unload at the touch of a button.
Advanced Electromagnetic Braking Technology:
Equipped with a smart electromagnetic braking system, this power barrow prioritizes safety by halting motion as soon as the throttle is released.
Quiet Operation with 8-10 Working Hours Charge:
Experience the benefits of a quiet, emission-free, and cost-effective battery-powered dumper with a substantial working range of 8-10 hours. Leave behind the days of manually pushing laden wheelbarrows!
Integrated Control Panel:
Stay informed with the HYMD500B’s integrated control panel, ensuring you are always aware of the power barrow’s energy levels, preventing any mid-task power surprises.
3-Year Warranty:
For added assurance, this Hyundai mini dumper comes with a 3-year platinum warranty* / 1-year commercial warranty* (terms apply).
Key Product Data:
| Model |
HYMD500B |
| Motor |
1000W Brushless DC |
| Voltage (V) |
48 |
| Battery Capacity (Ah) |
32 |
| Brake System |
Electromagnetic |
| Light Specification (W) |
1 x 30W LED |
| Working Time (Fully Charged) (Hours) |
8-10 |
| Charging Times (Hours) |
6-7 |
| Forward Speeds (mph) |
Speed 1 = 3.3 Speed 2 = 4.2 Speed 3 = 5.0 |
| Maximum Load (kg) |
500 |
| Tipping |
Hydraulic Power Unit (HPU) |
| Fully Assembled Dimensions (mm) (H x W x L) |
1130 x 760 x 1720 |
| Bucket Dimensions (mm) (L x W x D) |
1090 x 690 x 540 |
| Bucket Volume (L) |
236 |
| Front Wheels |
16x6.5-8 Tubeless Tire 325mm diameter |
| Rear Wheels |
13x5.00-6 Tubeless Tire 400mm diameter |
| Gross Weight (kg) |
242 |
| Net Weight (kg) |
212 |
| Model EAN |
5059608366150 |
| In The Box |
Bucket Guard, Bucket, Main Body, Left Handle, Right Handle, Wheels, Rear Axle and Wheels, Battery Charger, Manual |
| Warranty (Years) |
3 |
| Commercial Warranty (Years) |
1 |
