Featuring a formidable 10hp motor and a spacious 500L tank, the HYSC100500DVSD provides an impressive output of 145psi / 10bar, ensuring ample compressed air supply for a wide range of applications. Whether you're operating in a spray shop, tire-fitting garage, large workshop, or small factory, this compressor is equipped to meet your compressed air needs with ease.
Crafted with high-quality components, including a reliable refrigerant compressor and a durable heat exchanger, the HYSC100500DVSD is built to withstand the rigors of industrial use while maintaining peak performance over time. Its advanced oil and gas separator system ensures that the air supply remains clean and free of contaminants, with oil presence reduced to less than 3ppm for superior air quality.
What sets the HYSC100500DVSD apart from traditional compressors is its Variable Speed Drive technology. Unlike fixed-speed models, the VSD technology adjusts the compressor's output in real-time to match the air flow required, maximizing energy efficiency and extending product lifespan. This not only reduces operational costs but also minimizes maintenance requirements, resulting in significant savings for the user.
Setting up the Hyundai HYSC100500DVSD Air Compressor is a breeze – simply connect the outlet and drain pipes, plug it in, and you're ready to go. Its user-friendly design makes installation and operation hassle-free, allowing you to focus on your work without unnecessary downtime.
Safety is paramount with the HYSC100500DVSD. Equipped with a 7” color touch-screen monitor and a range of integrated safety features, including maintenance alerts and automatic shutdown after 24 hours of inactivity, this compressor prioritizes user safety and peace of mind.
Whether you're a professional mechanic, a DIY enthusiast, or a small business owner, the Hyundai HYSC100500DVSD Permanent Magnet Screw Air Compressor with Dryer and Variable Speed Drive offers unmatched performance, efficiency, and versatility for all your compressed air needs. Experience the difference with Hyundai's innovative air compressor technology – upgrade to the HYSC100500DVSD today!
Key Product Features:
- 10 hp 3-phase motor
- 500 Litre air tank
- Fully enclosed sound reduction canopy
- Digital control panel
- 36 cfm @ 8bar
- Maximum pressure 10 bar
- Forklift transport guides
Technical Specification
| Model |
HYSC100500DVSD |
| Start Method |
Electric |
| Fuel/Power Source |
Electric Hard Wired |
| Drive Type |
VSD Direct Drive |
| Tank Capacity (L) |
500 |
| Tank Material |
Steel |
| Duty Cycle |
S1 100% |
| Cut-In Pressure (psi/bar) |
101.5/7 |
| Cut-Out Pressure (psi/bar) |
116/11.5 |
| Discharge Pressure (psi/bar) |
145/10 |
| Max Pressure (psi/bar) |
145/10 |
| Air Flow FAD (L/min) |
940 @ 8 bar / 855 @ 10 bar |
| Air Flow FAD (CFM) |
36 @ 8 bar / 31 @10 bar |
| Air Displacement (L/min) |
990 @ 8 bar / 900 @ 10bar |
| Air Displacement (CFM) |
31.7 |
| Air Outlet Connection |
G3/4 |
| Outlet Pressure Regulation Type |
Fixed |
| Phase |
Three |
| Rated Power (kW) |
9.5 |
| Motor Power kW/hp |
7.5/10 |
| Pump (RPM) |
2700 |
| Speed (RPM) |
2700 |
| Frequency (Hz) |
50 |
| Noise Level @ 7m (dB) |
65 |
| Integral Air Dryer? |
Yes |
| Gross Weight (kg) |
420 |
| Net Weight (kg) |
380 |
| Fully Assembled Dimensions (H x W x L) (mm) |
1620 x 670 x 1700 |
| Packaged Dimensions (H x W x L) (mm) |
1860 x 790 x 1750 |
| Product Type |
Air Compressor |
| Warranty (years) |
2 |
| Model EAN |
5059608206524 |
| In The Box |
Air Compressor & User Manual |
