Fujitsu Air Conditioning UTY-VMSX MODBUS Integration Interface – Efficient BMS Connectivity
The Fujitsu UTY-VMSX MODBUS Integration Interface is designed to seamlessly connect Fujitsu air conditioning units to a MODBUS network, enabling centralised control and monitoring through a Building Management System (BMS) or Home Controller. With its compact and small form factor, installation is straightforward and requires no external power supply, making it a convenient and hassle-free solution for integrating air conditioning systems into existing MODBUS networks.
The UTY-VMSX is built for efficiency, allowing each unit to be connected individually for precise management. This interface permits central control over multiple air conditioners, ensuring streamlined operations and monitoring from a single point. Whether for commercial buildings or home automation, this MODBUS controller enhances the flexibility and efficiency of your cooling system.
Key Features:
- Simple, compact design for easy installation
- No separate external power supply required
- Connects one by one to each indoor unit for individual control
- Enables centralised monitoring and control from BMS or home automation systems
- Ideal for both commercial and residential applications
Technical Specifications:
- Power Source: DC 12V
- Dimensions: Height: 140 mm, Width: 117 mm, Depth: 43 mm
- Weight: 200 g
The Fujitsu UTY-VMSX MODBUS Integration Interface is the ideal solution for integrating Fujitsu air conditioners into MODBUS networks, providing enhanced control, efficiency, and ease of operation.
|
Model name
|
UTY-VMSX
|
|
Power supply
|
AC220/240V 50/60Hz AC208/230V 60Hz
|
|
Input Power
|
W
|
Max. 1.2
|
|
Temperature
|
Operating / Packaged
|
ºC (ºF)
|
0~46(32~114) / -10~60(14~140)
|
|
Humidity
|
Operating / Packaged
|
%
|
0~95 / 0~95
|
|
Dimensions (H×W×D)(in.)
|
mm (in.)
|
43 × 117 × 140
|
|
Weight(oz)
|
g (oz)
|
200(7)
|
|
Maximum Connectable indoor unit number per 1 MODBUS Convertor
|
1
|
|
List Price
|
225
|
PDF Data:
