Introducing the Clarke CXR20N Industrial Screw Air Compressor, engineered to excel in demanding industrial environments. With a robust 20hp motor and a capacity of 65.3cfm at 145psi/10bar, this compressor ensures reliable performance across a variety of applications.

Designed for space efficiency, the CXR20N features a compact build, facilitating easy installation. Its compatibility with pallet trucks allows for effortless transportation, while straightforward connections to air systems and electrical supplies ensure quick setup and minimal downtime.

Equipped with an advanced controller featuring a backlit display, this compressor offers comprehensive monitoring and control functionalities. From its weekly programmable timer to remote control capabilities and auto-restart functionality after power failures, it enhances operational efficiency. Maintenance planning, real-time monitoring of compressor and fan status, oil temperature regulation, and alarm logging further ensure seamless operation.

Technical features such as an electro-pneumatic system optimise energy usage by conserving pressure during idle periods. The inclusion of a Poly-V belt ensures durability and reduces maintenance requirements. A thermostatically controlled fan maintains optimal cooling, effectively reducing noise levels for quieter operation.

Moreover, wide front and rear panelling facilitate easy access for maintenance tasks. An oversized suction filter ensures maximum air intake filtration, minimising maintenance needs and extending the compressor's lifespan.

In terms of specifications, the Clarke CXR20N features a 20hp motor operating at 400V~50Hz. With its reliable performance and user-friendly design, this compressor is poised to enhance efficiency and productivity in industrial environments.

Key Features:

• Large oil separator tank ensures minimal oil carry over (typically as low as 3mg/m3)
• Minimum pressure valve ensures correct oil pressure & lubrication
• Thermostatic valve controls oil temperature and prevents condensation developing inside the oil separator tank
• Suction valve adjusts compressor output
• Over sized suction filter ensures maximum air intake filtration, thereby reducing maintenance and extending oil and compressor life
• 400V - 3 Phase Motor
• Power: 20HP/15kW
• 10bar Maximum Pressure
• 65.3cfm Air Displacement
• Dimensions (LxWxH): 800x650x980mm
• Weight: 200kg

Technical Specifications:
