Oil Fired Space Heater Home / Heating / Oil Fired Space Heater / Arcotherm EC32DV Diesel Space Heater Dual Voltage 230V~50Hz/60Hz Arcotherm EC32DV Diesel Space Heater Dual Voltage 230V~50Hz/60Hz Arcotherm EC32DV Diesel Space Heater Dual Voltage 230V~50Hz/60Hz £1,875.00 £1,562.50 (ex. VAT) Stock Status: In Stock Accessories: Not Required Heavy duty thermostat -5C/+50C, cable 10m, plug 90 (+£78.00) Fuel tank filler filter (+£25.50) Stainless Steel Flue 1mtr x 150mm (+£112.50) Rain Cowl 150mm (+£105.00) EC32 Rain Cover (+£210.00) Ducting 3mtr x 300mm (+£180.00) Ductig 7.6mtr x 300mm (+£300.00) Standard Diffuser 300mm (+£225.00) Low Level Diffuser 300mm (+£570.00) Fuel Level Gauge (+£78.00) Information Reviews The Arcotherm EC32DV is a dual voltage direct diesel space heater, designed to deliver efficient and reliable performance in industrial, commercial, and agricultural environments. This unit offers a rated heat output of 34.1kW and features high-grade safety systems and componentry. It is equipped with a robust AISI 430 stainless steel combustion chamber with three smoke loops, increasing heat exchange efficiency and reducing fuel consumption. Key Product Features Built-in diesel burner for direct combustion heating Electronic flame control for enhanced safety Integrated safety thermostat with manual reset Compatible with external thermostats, humidistats, or timers 1.5 metre power cord with standard plug included Stainless steel combustion chamber with three smoke revolutions for improved efficiency Automatic post-ventilation to cool the combustion unit Hydrocarbon-resistant rubber fuel lines with reinforced textile protection Durable polyethylene fuel tank with bayonet-type cap and drain plug Integrated electric control panel for operational convenience Technical Specifications Model: EC 32DV Rated Heat Power: 34.1kW Rated Heat Power (kcal/h): 28,349 Rated Heat Power (BTU/h): 116,803 Output Heat Power: 28.9kW Heat Efficiency: 84% Air Flow: 1,150 m³/h Temperature Rise (at 20°C): 75°C Fuel Consumption: 2.74 kg/h Tank Capacity: 42L Electrical Power Consumption: 460W Voltage: 230V~50Hz/60Hz (Dual Voltage) Flue Diameter: 120mm Dimensions (mm): A: 1075 x B: 440 x C: 615 Weight: 36kg Ideal Applications Construction site heating Agricultural barns and workshops Industrial warehouses Temporary event structures Emergency and backup heating Disclaimer This heater must be operated in well-ventilated spaces. Installation and use must follow manufacturer safety guidance. Images are illustrative. Not yet reviewed Write an online review and share your thoughts with other shoppers! Be the first to review this product
The Arcotherm EC32DV is a dual voltage direct diesel space heater, designed to deliver efficient and reliable performance in industrial, commercial, and agricultural environments. This unit offers a rated heat output of 34.1kW and features high-grade safety systems and componentry. It is equipped with a robust AISI 430 stainless steel combustion chamber with three smoke loops, increasing heat exchange efficiency and reducing fuel consumption. Key Product Features Built-in diesel burner for direct combustion heating Electronic flame control for enhanced safety Integrated safety thermostat with manual reset Compatible with external thermostats, humidistats, or timers 1.5 metre power cord with standard plug included Stainless steel combustion chamber with three smoke revolutions for improved efficiency Automatic post-ventilation to cool the combustion unit Hydrocarbon-resistant rubber fuel lines with reinforced textile protection Durable polyethylene fuel tank with bayonet-type cap and drain plug Integrated electric control panel for operational convenience Technical Specifications Model: EC 32DV Rated Heat Power: 34.1kW Rated Heat Power (kcal/h): 28,349 Rated Heat Power (BTU/h): 116,803 Output Heat Power: 28.9kW Heat Efficiency: 84% Air Flow: 1,150 m³/h Temperature Rise (at 20°C): 75°C Fuel Consumption: 2.74 kg/h Tank Capacity: 42L Electrical Power Consumption: 460W Voltage: 230V~50Hz/60Hz (Dual Voltage) Flue Diameter: 120mm Dimensions (mm): A: 1075 x B: 440 x C: 615 Weight: 36kg Ideal Applications Construction site heating Agricultural barns and workshops Industrial warehouses Temporary event structures Emergency and backup heating Disclaimer This heater must be operated in well-ventilated spaces. Installation and use must follow manufacturer safety guidance. Images are illustrative.
The Arcotherm EC32DV is a dual voltage direct diesel space heater, designed to deliver efficient and reliable performance in industrial, commercial, and agricultural environments. This unit offers a rated heat output of 34.1kW and features high-grade safety systems and componentry. It is equipped with a robust AISI 430 stainless steel combustion chamber with three smoke loops, increasing heat exchange efficiency and reducing fuel consumption. Key Product Features Built-in diesel burner for direct combustion heating Electronic flame control for enhanced safety Integrated safety thermostat with manual reset Compatible with external thermostats, humidistats, or timers 1.5 metre power cord with standard plug included Stainless steel combustion chamber with three smoke revolutions for improved efficiency Automatic post-ventilation to cool the combustion unit Hydrocarbon-resistant rubber fuel lines with reinforced textile protection Durable polyethylene fuel tank with bayonet-type cap and drain plug Integrated electric control panel for operational convenience Technical Specifications Model: EC 32DV Rated Heat Power: 34.1kW Rated Heat Power (kcal/h): 28,349 Rated Heat Power (BTU/h): 116,803 Output Heat Power: 28.9kW Heat Efficiency: 84% Air Flow: 1,150 m³/h Temperature Rise (at 20°C): 75°C Fuel Consumption: 2.74 kg/h Tank Capacity: 42L Electrical Power Consumption: 460W Voltage: 230V~50Hz/60Hz (Dual Voltage) Flue Diameter: 120mm Dimensions (mm): A: 1075 x B: 440 x C: 615 Weight: 36kg Ideal Applications Construction site heating Agricultural barns and workshops Industrial warehouses Temporary event structures Emergency and backup heating Disclaimer This heater must be operated in well-ventilated spaces. Installation and use must follow manufacturer safety guidance. Images are illustrative.
